Elitewheels Drive Disc Brake 40D Carbon Wheelset (Shimano Freehub/XDR Freehub)

$1,680.00

The Drive 40D is dedicated to those who want an all-rounder that is more geared towards riding in the hills and mountains. The wheelset features carbon spokes, light and stiff UNI carbon fiber as well as high precision, ceramic bearing hubs. It is tubeless ready and has the added benefit of having a 21mm internal rim width. The Drive 40D wheelset is for those who want professional-level wheels at a consumer friendly price. It comes in at only 1260g for the pair.

Elitewheels Drive Disc Brake 40D 2
This item: Elitewheels Drive Disc Brake 40D Carbon Wheelset (Shimano Freehub/XDR Freehub)
Freehub
Shimano
XDR
Hub Colour
Black
Silver
Decal
Black
Silver
$1,680.00
$1,680.00
Vittoria Corsa Pro TLR Gumwall (28mm) 1 DeNoiseAI standard min
$108.00
Vittoria Corsa Pro TLR Gumwall (28mm) 1 DeNoiseAI standard min
$108.00
Important Notes

*picture is for illustration purpose only*



Product Details

1 2

Drive 40mm disc brake carbon spoke wheelset Rims

DRIVE RIMS

At Elitewheels, we design our Drive wheels to match the needs of professional riders. In order to deliver the best performance, we incorporate our own UNI carbon fiber, a specific ratio of T800 and T1000 carbon fiber (*Read more about UNI technology)making rims not only strong, but also exceptionally light and stiff. The U/V-shaped rim profile of the Drive 40D was chosen to make the rim both aero as well as stable in windy conditions. The DRIVE 40D’s 21mm inner rim allows for wider tires to be run, allowing for more comfort and grip.

Drive 40mm disc brake wheelset Carbon Spokes

CARBON SPOKES

What separates the Drive 40D from most other wheels is its use of high-modulus carbon spokes. They are 3.3mm wide aero bladed spokes, offering 7% more lateral stiffness as compared to equivalent steel spokes. The carbon spokes are mechanically secured, giving the benefit of being able to be trued and maintained just like regular steel spokes. Anti-loosening technology is also incorporated into the spoke nipples. The threads built into the nipples give them a double-locking effect.

Drive 40mm disc brake carbon spoke wheelset Performance hub

PERFORMANCE HUB

To get the most out of carbon fiber spokes, we specifically designed the hub with high flanges to further increase lateral stiffness and improve handling. Elitewheels manufactures its own high precision hubs with Fanuc CNC machines, which can machine to tolerances of just 0.02mm. This not only allows for lower rolling resistance but also increases bearing longevity.

Drive 40D ceramic bearings

CERAMIC BEARINGS

The 40D’s front hub uses two 6803 mixed ceramic bearings. The rear hub uses one 6903 and three 6803 mixed ceramic bearings. These large bearings offer better rigidity. The use of mixed ceramic bearings will allow you to have a more efficient bike, saving you precious watts.



Measurements

Rim
Series:Drive 40D
Wheel Size: 700c
Tire Compatibility: Clincher/ Tubeless
Rim Depth: 40mm
Inner Width: 21mm
Outer Width: 28mm
Rim Finish: Glossy Marbling Black

Hub
Front Hub Spacing: 12x100mm / QR x 100mm
Rear Hub Spacing: 12x142mm / QR x 135mm
Bearing: S&S Ceramic
Brake Compatibility: Disc (Center Lock)
Freehub Type: 4 Pawls
Compatibility: Shimano / SRAM XDR

Spoke
Front Spoke Pattern: 2X/Radial (2:1)
Rear Spoke Pattern: 2X/1X (2:1)
Spoke Count: 21F/24R
Spoke Type: Carbon cs-01
Nipple Type: Alloy Secure Lock

Other
Extras: Extras: Rim tape(Installed), Tubeless Valves(Installed), Spokes(4)
Weight (Pair): 1260±30g
Rider Weight Limit: 275lbs/130kg
Recommended Tire Sizes: 700 x 25-38C
Certification: UCI Approved



FAQ

Which brand’s freehubs are compatible with Drive Wheelsets?
Since the hubs used in Drive wheels are manufactured in Elitewheels’ factory, freehubs from other brands are incompatible. The hubs used in Drive wheels have passed our 20,000km test. As long as you ride in normal conditions, the possibility of the freehub getting damaged is very low. If you ride in extreme conditions, we recommend you clean the freehub every 3000km.

Can I use disc brake wheels on my QR (quick release) compatible frame?
Yes. When placing the order for your disc brake wheelset, please leave a note saying that you would like quick releases instead of thru-axles.

Is there an internal nipple option?
Internal nipples are not available because the nipples for carbon spokes are specially processed. The contact angle between spokes and spoke holes is extremely important. Spokes should not directly come into contact the rim directly, otherwise there would be a high likelihood of having spoke break.

Can I change to 6-bolt?
Yes. Drive uses center lock hubs by default, but if you want to use 6-bolt, contact us and we will send you an adapter at no extra cost.

Are ceramic bearings easily broken?
As all our our hubs have high-precision manufacturing tolerances, bearing play is significantly reduced. Because of this, the likelihood of bearings being damaged is extremely low.

What does the rider weight limit include?
The rider weight limit includes the total weight of the rider, bike, gear, and any other accessories. Please do not exceed this weight.

What tire pressures should I run?
The best tire pressure for you depends on many factors: the rim width, type of bike and tires, rider weight, road conditions and weather conditions.
