Marvel wheelset are for those who are looking for performance on a budget. Our entry level wheels are anything but, featuring ceramic bearings and Pillar spokes. They are tried and tested all-rounders that are available in rim depths from 38-82mm.
Elitewheels Marvel Rim/Disc Brake 38mm/50mm/60mm/82mm Carbon Wheelset (Shimano Freehub/XDR Freehub)
$880.00 – $980.00
This item: Elitewheels Marvel Rim/Disc Brake 38mm/50mm/60mm/82mm Carbon Wheelset (Shimano Freehub/XDR Freehub)
$880.00 – $980.00
$880.00 – $980.00
2 × Vittoria Corsa Control Clincher Road Tyre (Black / Tanwall) - Black, 30c
Only 1 left in stock
$68.00
Important Notes
*picture is for illustration purpose only*
Product Details
RIMS
Marvel wheels are available in multiple depths. Their aerodynamic design makes them fit for training and racing, saving you precious watts. The rims are designed to be strong and stiff, making for a not only a wheel that is durable and long lasting, but also giving you excellent power transfer during hard efforts.
BRAKE SURFACE
Marvel uses a blend of 270 ℃, high-temperature resin developed by Elitewheels and Japan’s Toray T800 carbon fiber for the brake surface. To ensure excellent braking performance even on long descents in the rain, the brake track has laser-etched grooves to clear water off.
HUB
Marvel wheels feature high flange hubs which offer greater lateral stiffness, improving stability. Both the front and rear wheel hubs feature ceramic bearings with an extremely low coefficient of friction, saving you precious watts. The front hub uses 6803 ceramic bearings and the rear hub uses three 6803 bearings and one 6903 bearing. The larger the bearing, the better the rigidity. Marvel wheels can also be upgraded to DT Swiss hubs upon request.
SPOKES
Marvel wheels use Pillar PA 1423 spokes in their standard configuration. An optional upgrade to Sapim CX-Ray spokes is also available.
TRD Technology
Marvel wheels make use of Elitewheels’ TRD (Tubeless R-angle Design). This design uses rounded edges to allow for effortless tire installation. All of our rims are tubeless compatible.
Measurements
Rim
Series:Marvel Wheel Size: 700c
Tire Compatibility: Clincher/Tubeless
Rim Depth: 38/50/60/82mm
Width: 7mm(38/50 depth) 18.5mm(60/82 depth)
Outer Width: 28mm
Spoke
Front Spoke Pattern: Radial
Rear Spoke Pattern: 2X/Radial (2:1)
Spoke Count: 18F/21R
Spoke Type: Pillar pa 1423
Nipple Type: Sapim Secure Lock
Hub
Front Hub Spacing: QR x 100mm
Rear Hub Spacing: QR x 130mm
Bearing: S&S Ceramic
Brake Compatibility: Rim Brake
Freehub Type: 4 pawls
Freehub Compatibility: Shimano / SRAM XDR
Other
Assembly Method: Handbuilt
Extras: Rim Tape(Installed), Tubeless Valves, Quick Releases, Brake Pads(2 Sets)
Rider Weight Limit: 285lbs/130kg
Recommended Tire Sizes: 700 x 23-33C
Max Tire Pressure: 120psi
Weight(pair):
38mm : 1615g±30g
50mm: 1692g±30g
60mm: 1807g±30g
82mm: 1946g±30g
FAQ
Is there an internal nipple option?
YES. MARVEL wheels come standard with external nipples. If you would like internal nipples instead, then we will have to produce new rims. It takes approximately 7-15 days to manufacture new rims. As they are not in stock, you will have to wait longer before receiving your wheels.
Are brake pads included? Can I use break pads from other brands?
Yes, we will put a pair of brake pads in the carton for every pair of MARVEL wheels. We recommend you contact us for replacement brake pads. If you order replacement pads from other brands, make sure they are suitable for carbon rims.
Are ceramic bearings easily broken?
As all our our hubs have high-precision manufacturing tolerances, bearing play is significantly reduced. Because of this, the likelihood of bearings being damaged is extremely low.
What does that rider weight limit include?
The rider weight limit includes the total weight of the rider, bike, gear, and any other accessories. Please do not exceed this weight.
