Without the need for a remote control, the EVO 1700SD connects directly to your bike’s Shimano Di2 system (wireless unit).But please note the light is NOT compatible with SHIMANO E-BIKE SYSTEMS.
LIGHT MODES
MODE LOW BEAM | HIGH BEAM | FLASH
LOW MEDIUM HIGH | LOW MEDIUM HIGH | DAY FLASH NIGHT FLASH
LUMENS 200LM 400LM 800LM | 400LM 800LM 1700LM | 0 – 1700LM 400 – 1700LM
h:min 11:00 05:30 03:00 | 06:00 03:00 02:00 | 05:00 03:30
SHIMANO Di2 INTEGRATION
Effortlessly adjust your light settings through Shimano Di2 buttons, as accessible as shifting gears.
Paring Guide:Initial Paring: Single click any button on the shifters to activate the SHIMANO Di2 system, then long press the light button for 1 second until the indicator flashes blue to enter pairing mode. Position the light to the rear derailleur within 30 cm. The indicator is constantly blue for 3 seconds, confirming a successful pairing.
Note:Before pairing, ensure your SHIMANO Di2 system has at least two unassigned buttons available to fully utilize product features.
